HD Portable Medical Video Recorder

Overview

Portable MediDVR, PMD2 – the second generation dual video input portable medical video recorder, is the first and most affordable, standalone, compact, and versatile high definition recorder solution. It combines superior image and video quality, extensive easy control, various removable storage media, modern USB Type-C charger, tripod mount, and a range of innovative features.

It is a standalone recorder, the internal battery can supply surgical recording up to 6+ hours. External medical grade power adapter or power bank can be connected for longer recording time or fully charge the battery in ~2 hours quickly while power off. It is as small as palm that you can take it anywhere with you.

It is a standalone recorder, the internal battery can supply surgical recording up to 6+ hours. External medical grade power adapter or power bank can be connected for longer recording time or fully charge the battery in ~2 hours quickly while power off. It is as small as a palm that you can take it anywhere with you.

New portable MediDVR has 4.3” resistive touch screen and user-friend operation even with gloves. Live PiP and collage can be preview, switch, setup by touch UI. PiP allow medical video and ECG displayed at the same screen and recorded. All recording, photo, patient, replay, storage status are available on screen. MediDVR can also be controlled remotely via mobile phone by simply scan the QR code on LCD.

Meanwhile, MediDVR supports real time streaming by connecting to the hospital network. It enables the live transmission of procedures to other practitioners or students outside of the operating theater for training or monitoring purposes on PC or iPad/iPhone.

Portable MediDVR is small size, universal and easy operation, no special training is required. It is just plug and play. It has universal video connectivity and compatibility, the dual video input formats enable compatibility and integration with virtually all modern surgical system manufactures. It accepts DVI, HD/3G SDI, and HDMI an well as 1080i50/60 or 1080p50/60. It also has SDI loop output.

The MediDVR can be used in almost unlimited number of situations, the major application is in medical imaging. No longer limited to paper or film-based images, and no longer any need for cumbersome DVD disks. The MediDVR allows you to easily record digital video and images directly to a flash drive or hard drive. You can archive and share your recordings on a secure hospital network, enhance them with third-party editing programs, etc.

MediDVR is designed for using in any medical environments.

Features

  • Portable and easily record crisp 1080p video and images
  • Low cost and easy operation
  • 6hr standalone video recording
  • Up to 20mbits/s high-quality video codec in H.264 format
  • Palm size, small form-factor, light and portable for filed and indoor
  • 4.3” LCD and resistance touch screen, friend to gloves and fingers
  • QR code scan for direct remote control by mobile phone or PC
  • Creative dual video inputs, live collage switch and preview
  •  AAC audio encoder with DVI/HDMI/SDI embedded audio support
  • Universal inputs with VGA, S-Video, YPbPr, S-Video analog support
  • Automatic video input resolution, format-detection
  • SDI loop out, HDMI loop out support
  • Support rtsp live video streaming in LAN
  • Still Image Photo and DICOM support
  • Optimized recording for medical image process
  • Mp4 and mov video format all supported
  • Footswitch, hand switch supported for remote control
  • The video formats support most video edit software
  • Instant replay to preview on LCD or monitor
  • Universal storage works with all major USB Flash, SD Card, USB HDD
  • Support Full HD video up to 1080p@60
  • Both HD and 3G SDI video inputs supported
  • Onboard and external microphone support, gain adjustable
  • Powerful patient information input and management
  • USB standard keyboard support for patient information and notes
  • Shortcuts to quickly switch video source and storage media
  • Small size, low cost, and high quality
  • Cost-effective and easy operation
  • Medical grade and certification.
  • Certificate: CE, FCC, EN60601-1, EN60601-2



Specifications

Power
Power Adapter USB TYPE C, up to 60W 20V 18V 2.2A DC Power, Medical Grade
Battery Lion, 19AH, Fast Charge
Consumption 18V@~1.15A max without ext. HDD
Video and Photo
Video Encoder H.264/AVC, MP/HP
Resolution 1920×1080 @25/30/50/60fps, 1280×720 @50/60fps
480i/576i 1080i@50/60
SMPTE 296M/274M/292M,425M/424M DVI/HDMI all resolution
Bit Rate Max. 20Mbits/s, 3 level adj.
Frame Rate 24/25/30fps, 50/60fps
Codec H.264, mp4/mov file format
Rate Control CBR/VBR
Photo Jpeg, DICOM, BMP
Network
LAN 100/1000M Base-T
Streaming RTSP
WIFI6 802.11b/g/n/ac, 2.4/5.8GHz
Audio
Sampling 32-48Khz 16bits
Codec AAC Stereo
MIC 2.2VDC Bias, 2.2Kohm, <0.7VRMS -36dB. MIC gain adj.
Channels 2, with Automatic Gain Control
Interface
3G SDI Input 1x BNC, 75ohm, 800mVpp, SD/HD/3G
DVI Input via HDMI/DVI adapter or cable
HDMI Input 1 x Type A, Receptacle
Preview LCD 4.3”
SDI Loop Out 1x BNC, 75ohm, 800mVpp, HD/3G SDI
Audio In 2CH 2 x 3.5mm, jack 20Kohm higher
Aduio Out 2CH, 2 x 3.5mm Jack
Network RJ45, 100/1000M Ethernet
USB 3 x USB,TYPE A
Alert Buzz
Visible Full Color LED
LCD 4.3” IPS, Resistance Touch
Remote Mobile phone, PC, RESTFUL
Button 1x Video, 1x Photo
Storage
External USB Flash Drive, USB HDD,TF
Disk Format FAT32, up to 2T
System Requirements
Interface USB 3.0 Interface
SATA Reader USB 3.0 SATA Reader
Ethernet 1000 Base-T Ethernet
Monitor Resolution 1920×1080
Physical
Size 131 x 85 x 42mm(5.15” x 3.34” x 1.65”)ABS
Weight 596g (1lb 5oz)
Operating 0°C to 45°C(32°F to 113°F)
Storage -20°C to 60°C(-4°F to 140°F)
  Certificate FCC, CE(EN60601-1, EN60601-2)

Download

Item Type Update Version
Spec PDF 22/01/10 1.0.0
Manual PDF 22/02/24 1.0.5
Firmware ZIP


Order Information

Product P/N
HD Portable Medical Digital Video Recorder, PMD2 30501-100

Accessories

USB Dual Foot Switch 68951-002
USB Triple Foot Switch 68951-003
USB Wireless Foot Switch Single 68953-001
USB Four Button Hand Switch 68952-004
USB Footswitch Extension Cable 68990-LLL(3/5/10m)
Accessories listed above are options are sold separately
