Universal PTZ Controller
Features
Four control modes: Two IP control modes (IP VISCA & ONVIF); Two analog control modes(RS422 & RS232)
Supports VISCA, Onvif PELCO-P and PELCO-D protocol
Four control modes: Two IP control modes (IP VISCA & ONVIF); Two analog control modes (RS422 & RS232)
Max up to 255 cameras
Adopt rocker switches and knobs
Adopt a 3D joystick to control the camera speed, rotation, zoom, aperture, focus.
Description
Zoom toggle, you now have the ability to zoom and pan the camera.
With the focus/ iris knobs, you can manually adjust the focal length and the aperture easily.
R/B and PTZ speed Control knobs, you can manually adjust the Red Gain and the Blue Gain. You can adjust PTZ Speed, Gears 1 (Slow)- 8(Fast).
Specification
Ethernet
One Ethernet port
Joystick
Four-Dimensional (up, down, left, right) Control Camera Rotation, Zoom, Aperture, Focus and Other Camera Parameter Settings
Connection
Lead
Display
LCD
Prompt Tone
Button Sound Prompts Open/Off
Power supply
DC 12V1A±10%
Power Consumption
0.6 W Max
Operating Temperature
0°C-50°C(32℉~122℉)
Storage Temperature
-20-70°C(-4℉~158℉)
Dimensions(mm)
320*180*100(13*7*3.8 inch)
Download
Item
Type
Update
Version
Download
Spec
PDF
08/07/21
–
Manual
PDF
08/07/21
–
Firmware
ZIP
08/07/21
–
Order Information
Item
P/N
Universal PTZ Controller
90950-220
Accessories
power adapter
America
Europe
Asia-Pacific
America
Europe
Asia-Pacific
